Embedded Memory Blocks in Stratix V Devices
2
SV51003
Subscribe
Send Feedback
The embedded memory blocks in the devices are flexible and designed to provide an optimal amount of
small- and large-sized memory arrays to fit your design requirements.
Related Information
Stratix V Device Handbook: Known Issues
Lists the planned updates to the Stratix V Device Handbook chapters.
Types of Embedded Memory
The Stratix V devices contain two types of memory blocks:
? 20 Kb M20K blocks — blocks of dedicated memory resources. The M20K blocks are ideal for larger memory
arrays while still providing a large number of independent ports.
? 640 bit memory logic array blocks (MLABs) — enhanced memory blocks that are configured from dual-
purpose logic array blocks (LABs). The MLABs are ideal for wide and shallow memory arrays. The MLABs
are optimized for implementation of shift registers for digital signal processing (DSP) applications, wide
shallow FIFO buffers, and filter delay lines. Each MLAB is made up of ten adaptive logic modules (ALMs).
In the Stratix V devices, you can configure these ALMs as ten 32 x 2 blocks, giving you one 32 x 20 simple
dual-port SRAM block per MLAB. You can also configure these ALMs as ten 64 x 1 blocks, giving you
one 64 x 10 simple dual-port SRAM block per MLAB.
